Marine boat high speed electric winch wireless remote control

FOB Reference Price:Get Latest Price
$7,150.00 - $86,860.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Name:
electric winch
Power source:
electric winch
Application:
boat electric winch
Capacity:
5~3000KN
Color:
Customized
Certification:
BV ABS CCS DNV etc.
Material:
Q235B / Q345B
Warrenty:
12 months
Driving type:
Electric or Hydraulic
Control:
Local and remote conrol
Supply Ability
Supply Ability:
1980 Set/Sets per Month
Packaging & Delivery
Packaging Details
Container / Wooden box
Export Standard Package
According to customer's request
Port
Shanghai Port , China
Lead Time :
2 months
Video Description
Product Description

Marine boat high speed electric winch wireless remote control / Boat winch

  Electric winch is mainly composed of  motor , reducer and gear (low speed or high speed motor), brake, gear box, drum, support shaft, frame, rope device (optional), etc. Hydraulic motor has high mechanical efficiency, and large starting torque. For large tonnage winch, hydraulic winch has obvious advantages compared with electric winch. Hydraulic winch is widely used in shipbuilding, railway, engineering machinery, petroleum, geological exploration, metallurgical and other industries, its good performance won the acceptance of the user. And it is the future development direction of winch.

  Our factory can be customized design common hydraulic winch,hydraulic anchor winch,hydraulic mooring winch,hydraulic anchor mooring winch,hydraulic towing winch according to different clients' specific requirements and all hydraulic winch equiped with high efficiency hydraulic pump station.

Related Products
Rated Pull
(KN)
Rated Speed
( m / min )
Drum Capacity
(m)
Motor Power (KW)
Electric Type
Motor Power (KW)
Hydraulic Type
5
≥ 12
φ 8mm * 100
3 / 1.2
---
10
≥ 12
φ 10 mm * 150
4.3 / 1.7
5.5
20
≥ 12
φ 15 mm * 150
8.5 / 3.5
11
30
≥ 15
φ 17 mm * 150
11 / 11 / 7.5
---
40
≥ 15
φ 18 mm * 150
16 / 16 / 11
22
50
≥ 15
φ 20.5 mm * 180
22 / 22 /16
30
75
≥ 15
φ 26 mm * 200
30 / 30 / 22
45
80
≥ 15
φ 26 mm * 200
30 / 30 / 22

100
≥ 15
φ 30 mm * 200
45 / 45 /30
45
125
≥ 15
φ 30 mm * 200
45 / 45 /30

160
≥ 15
φ 32 mm * 250
60 / 60 / 45
75
200
≥ 9.6
φ 41 mm * 250
45 / 45 /30
75
250
≥ 9.6
φ 44.5 mm * 250
60 / 60 / 45
90
315
≥ 7.8
φ 52 mm * 250
60 / 60 / 45
90
400
≥ 7.8
φ 56 mm * 250
85 / 85 / 64
110
500
≥ 7.8
φ 58 mm * 250
85 / 85 / 64
110
560
≥ 6
φ 64 mm * 250
85 / 85 / 64
132
650
≥ 6
φ 70 mm * 250
85 / 85 / 64
132
1000
≥ 4
φ 85 mm * 250
85 / 85 / 64
132
1200
≥ 4
φ 95 mm * 250
120 / 120 / 90
160
1500
≥ 4
φ 95 mm * 250
150 / 150 / 72
200
1800
≥ 4
φ 95 mm * 250
150 / 150 / 72
250
2000
≥ 4
φ 100 mm * 250
180 / 180 /270
270

We need you confirm below information when you send inquiry to us :

[ Noted:tell me your email and whatsapp or skype or other contact information ] THANK YOU

1.Your need quantity?(Set)
2.FOB price or CIF price?(If need CIF price,kindly tell us your nearest sea port)
3.Which kind of hydraulic winch?(towing winch,anchor winch,mooring winch,anchor mooring winch)
4.Rated pull force/loading capacity?(KN/Ton)
5.Working speed?(m/min)
6.Numbers of gypsy wheel?(If anchor winch and anchor mooring winch,you need provide this item)
7.Anchor chain diameter and anchor weight?(mm Ton)(If anchor winch and anchor mooring winch,you need provide this item)
8.Rope capacity and Rope diameter?(m mm)
9.Any other special requirements?
